Wilwood Rear 11″ Disc Brake Conversion – Chevy 10 &12 Bolt Car 67-02

PN: 140-11398

$932.00

(0) Review this Product

Application: 67-78 Chevy Cars, 67-2002 Camaro/Firebird, 10 & 12 Bolt Axles With 2.75, 2.81 or 2.91″ Offset



Not sure which axle you have? Click HERE

Need to match OEM size front 11″ rotors? This is your kit. This kit pretty much will fit in ALL 15″ wheels and will fit many 14″ steel wheels. Sizing chart available.

Adding disc brakes to your rear axle will create the best possible braking combination for your street rod or muscle car. You will notice shortened stopping distances, reduced fade and improved brake feel. Our Wilwood Pro Series Kit utilizes an OEM compatible 11.00″ vented .81″ thick iron rotor. Inside the rotor are Wilwoods patented internal e-brake with huge holding power. This hidden mechanical e-brake is designed to easily mate with your OEM cables.  Clamping duties are accomplished with the Wilwood 4 piston Dynapro Low Profile forged aluminum calipers. As the name implies, these forged billet calipers are much lighter, more rigged and very slim compared to your OEM iron calipers. Considered one to the best calipers made, these slender units incorporate stainless internals and use an “over the counter” shaped pad. This great looking package creates huge stopping power, quicker cooling and is constructed of long life components designed specifically for the heavier US muscle car. This kit is only available for axles with a 2.75″, 2.81″ or a 2.91″ offset! Call if you need assistance in how to measure (ouside surface of axle housing end bracket to outer surface of wheel mounting pad on axle) .





Rear Disc Kit Contents

  • 11.00″ Wilwood Smooth Iron Rotors
  • Dynapro Low Profile Forged 4 Piston Calipers
  • Caliper Brackets
  • All Hardware
  • BP110 Compound Street/Race Pads
  • Internal e-brake Kit
  • Instructions

Base kit includes BLACK calipers and SMOOTH rotors.

Base shock configuration is parallel. Staggered option below

Rotors are dual bolt pattern: Ford 5x 4.5″ and GM 5x 4.75″ respectively

  • Summary
  • Details
  • Review

Additional information

Weight 49 lbs
